vJSONRenderFlowField
Render a noise-driven flow field of line segments.
Mograph / JSONJSONScriptValArray
Parameters
| Parameter | Type | Default | Description |
|---|---|---|---|
| Rows | Integer | 20 | Rows of line segments. |
| Columns | Integer | 35 | Columns of line segments. |
| Line Length | Float | 0.025 | Length of each segment. |
| Line Width | Float | 0.002 | Width of the lines. |
| Noise Scale | Float | 3.0 | Scale of the noise. |
+8 more parameters
| Parameter | Type | Default | Description |
|---|---|---|---|
| Noise Offset X | Float | 0.0 | Shifts the noise along X. |
| Noise Offset Y | Float | 0.0 | Shifts the noise along Y. |
| Animation Speed | Float | 0.0 | — |
| Red | Float | 1.0 | Color for the line. |
| Green | Float | 1.0 | Color for the line. |
| Blue | Float | 1.0 | Color for the line. |
| Alpha | Float | 1.0 | Color for the line. |
| Input | Image | — | Image that the result is drawn onto. |
