vTextFromCSVViewer
View a CSV row or column in the Inspector
Core / TextText
Parameters
| Parameter | Type | Default | Description |
|---|---|---|---|
| Array Mode | Dropdown | Extract Row | How the CSV is read — a single Row or Column by Index, or the whole CSV rendered as a Grid by row or column. |
| Index | Integer | 1 | Row or Column number to extract, used in Extract Row/Extract Column mode. |
| Ignore Header Row | Integer | 0.0 | Offsets the first index position to skip a labelled header line. |
| Input | Text | — | The CSV-formatted block of text to view. |
| Show Dump | Integer | 0.0 | Prints diagnostic output to the Console window. |
+3 more parameters
| Parameter | Type | Default | Description |
|---|---|---|---|
| Show Input | Integer | 1.0 | Reveals the wire for the Input connection in the Flow view. |
| Display Lines | Integer | 25 | Number of lines shown in the Input text box in the Inspector. |
| ScriptVal | ScriptVal | — | Read-only — the extracted row/column/grid data, shown in a ScriptVal viewer. |
