vImageRouter
Control the output routing of a Fusion Image object
Core / ImageImage
Parameters
| Parameter | Type | Default | Description |
|---|---|---|---|
| Which | Integer | — | Selects which output receives Input: 1 sends it to Output1 (Output2 gets an empty image), any other value sends it to Output2 instead. |
| Input | Image | — | The image to route to one of the two outputs. |
| Show Input | Integer | 1.0 | Reveals the wire for the Which control in the Flow view (despite the name, this toggles Which's visibility, not Input's). |
